Futaba GYC480 All-Purpose RC Car Gyro
See All:
Radio Accessories
Description
Equipped with UR mode for direct operation even through the gyro. The classic grip gyro GYC470 has been redesigned with the addition of UR mode!
FeaturesAngular Velocity Detection Method: Vibration Gyro Sensor
Operating Voltage: DC 4.0V - 8.4V
Current Consumption: 30mA (when servo is not connected)
Operating Temperature: -10°C - 45°C
Functions: Monitor LED, S.BUS/S.BUS2 Compatible
FunctionsCompatible with the F-4G's UR/SR mode servos for high-speed response system.
Remote gain function: Set the gyro sensitivity from the transmitter. (A transmitter/receiver with 3 or more channels and capable of adjusting the steering angle of 3 channels is required.)
Settings specifically for RC cars: While suppressing the effects of road surfaces, etc., the synergistic effect with UR mode response provides comfortable straight-line and cornering performance to help improve lap times.
Ultra-compact and lightweight: Ultra-compact and lightweight design achieved through full use of high-density mounting technology.
Compatible with S.BUS systems (can also be used with systems other than S.BUS): Can be connected via S.BUS in combination with an S.BUS receiver.
For digital servos only: For use with Futaba HPS/BLS servos and digital servos only. Analogue servos cannot be used.
Normal/AVCS mode.
High-speed response mode.
Turn-in adjustment.
Gyro curve adjustment.
Left and right endpoint adjustment.
EXP rate adjustment.
Stick priority mode adjustment.
Support wireless adjustment function.
Note: Wireless settings are only available for F-4G systems: T10PX, T6PV, R404SBS and R404SBS-E. A software update is required for T10PX, T6PV, R404SBS, and R404SBS-E to enable wireless settings for GYC480 and GYD560.
Features
Functions
Note: Wireless settings are only available for F-4G systems: T10PX, T6PV, R404SBS and R404SBS-E. A software update is required for T10PX, T6PV, R404SBS, and R404SBS-E to enable wireless settings for GYC480 and GYD560.
More Information
| Part Number | FUT05102754-3 |
|---|---|
| Manufacturer | Futaba |
