Futaba S-AG500 Corelss Slim Digital Servo PWM/S.Bus2 9.5kg 0.12s 6.0V - 7.4V
See All:
Servos
Description
The Futaba S-AG500 Coreless Slim Digital Servo is a specialized, high-performance component designed primarily for glider wings and other applications where space is extremely limited.1 Its primary feature is its ultra-thin 10mm profile, allowing it to fit into narrow airfoils while still delivering high torque.
FeaturesHigh Voltage (HV) Support: Designed to operate on a voltage range of 6.0V to 7.4V, allowing for direct power from 2S LiPo receiver packs.
S.Bus2 Integration: Fully compatible with Futaba’s S.Bus and S.Bus2 systems, enabling simplified wiring and programmable parameters for custom setups.
Coreless Motor: The high-efficiency coreless DC motor provides smoother operation and faster response times compared to standard motors.
All-Metal Construction: Features durable metal gears and a full aluminum case, which helps with heat dissipation and adds structural rigidity.
Dual Ball Bearings: Equipped with dual ball races to ensure precision and long-term durability under flight loads.
SpecificationThickness: 10 mm (0.39 in)
Weight: 28 g (0.99 oz)
Torque (7.4V): 9.5 kg-cm
Speed (7.4V): 0.12 sec/60°
Dimensions: 30.0 x 10.0 x 35.5 mm
Gear Type: Metal
Case Material: Aluminium
Features
Specification
More Information
| Part Number | FUT05102761-3 |
|---|---|
| Manufacturer | Futaba |
